Dimensions
Corded: 7.3 in. H x 3.0 in. W x 5.2 in. D 18.5 cm H x 7.6 cm W x 13.2 cm D Cordless: 7.3
in. H x 3.0 in. W x 5.6 in. D 18.5 cm H x 7.6 cm W x 14.2 cm D
Input Voltage Range
Host powered: 4.5 VDC min., 5.5 VDC max. External power supply: 11.4 VDC min., 12.6 VDC max.
Operating Current
Standby Current
Supported Host Interfaces
User Indicators
Performance chaRacteRistics
Scans per Full Charge
70,000+
Illumination
Two (2) 617nm Amber LEDs
Imager Field of View
35°
Image Sensor
1,500 pixels
Minimum Print Contrast
15% minimum reflective difference
Skew/Pitch/Roll
Skew: ± 65°; Pitch: ± 65°; Roll: ± 45°
decode caPabilities**
1D
Code 39, Code 128, Code 93, Codabar/NW7, Code 11, MSI Plessey, UPC/EAN, I 2 of 5, Korean
3 of 5, GS1 DataBar, Base 32 (Italian Pharma)
useR enViRonment
Operating Temp.
Corded: -22° F to 122° F/-30° C to 50° C Cordless: -4° F to 122° F/-20° C to 50° C
Storage Temp.
-40° F to 158° F/-40° C to 70° C
Humidity
5% to 95% condensing
Drop Specification
Withstands multiple 8.0 ft. / 2.4 m drops to concrete
Tumble Specification
5,000 tumbles @ 3.3 ft. (1 m)
Sealing
Scanner: IP65 and IP67; FLB cradle: IP65
ESD
Per EN61000-4-2, ±25 KV air discharge, ±10 KV direct discharge, ±10 KV indirect discharge
Ambient Light Immunity
0 to 10,037 Foot Candles/0 to 108,000 Lux (direct sunlight)
utilities and maintenance
123Scan2
Programs scanner parameters, upgrades firmware, provides scanned barcode data and prints reports. For more information, visit
www.zebra.com/123Scan
Scanner SDK
Generates a fully-featured scanner application, including documentation, drivers, test utilities and sample source code.
For more information, visit www.zebra.com/windowsSDK
Scanner Management Service (SMS)
Remotely manages your Zebra scanner and queries its asset information. For more information, visit www.zebra.com/sms
wireless connectivity
Bluetooth Radio
Bluetooth Class 1, Version 4.0 (LE), serial port and HID profiles
Data Rate
3 Mbit/s (2.1 Mbit/s) for Classic Bluetooth 1 Mbit/s (0.27 Mbit/s) for Low Energy
Radio Range
Direct line of sight in open air : Class 1: Up to 300 ft. (100.0 m) Class 2: Up to 30 ft. (10.0 m)
RegulatoRY
Environmental
RoHS EN 50581: 2012
Electrical Safety
EU Safety: EN 60950-1: 2006 + A11: 2009 + A1: 2010 + A12: 2011 + AC 2011 + A2: 2013
International
Safety
: IEC 60950-1: 2005 + A1: 2009 + A2: 2013 US/Canada Safety: UL 60950-1, second
edition, CAN/CSA-C22.2 No. 60950-1-07/p>
LED Safety
International LED Safety: IEC 62471: 2006 (Ed.1.0); EN 62471: 2008 (LED)
EMI/RFI
IT Emissions: EN 55022: 2010/AC: 2011 (Class B)
IT Immunity: EN 55024: 2010
Heavy Industrial: EN 61000-6-2: 2005/AC:2005
Harmonic Current Emissions:
EN 61000-3-2: 2006 + A1: 2009 + A2: 2009 (Class B)
Voltage Fluctuation and Flicker:
EN 61000-3-3: 2013
Medical Electrical Equipment: EN 60601-1-2: 2007/AC: 2010, IEC 60601-1-2:
2007 (Modified) Radio Frequency Devices: 47 CFR Part 15, Subpart B, Class B
Digital Apparatus: ICES-003 Issue 5, Class B
WaRRantY
Subject to the terms of Zebra’s hardware warranty statement, the LI3608 is warranted
against defects in workmanship and materials for a period of three (3) years
from the date of shipment. For complete warranty statement, go to: http://www.zebra.com/warranty
Recommended seRVices
Zebra OneCare Select; Zebra OneCare Essential
decode Ranges
Symbology/Resolution
Code 128: 5 mil
Code 128: 20 mil
Code 128: 40 mil
Datamatrix: 7.5 mil
Datamatrix: 10.0 mil
Near/Far
1.3-6.7 in./3.3-17 cm
2.8-28.0 in./7.1-71.1 cm
1.7-60 in./4.4-152.4 cm
1.9-6.0 in./ 4.8-15.2 cm
1.4-8.6 in./3.5-21.8 cm
