Independently certified to meet IP66 standards for moisture and particle resistance
System Architecture
Processor
Intel® Atom Z530 1.6GHz
Operating System
Microsoft® Windows® CE 6.0, Microsoft® Windows® Embedded Standard 2009 (WES 2009)
Memory
1GB for Microsoft® Windows® CE or 2GB for WES DDR2 SDRAM
System Software
Microsoft® Windows® CE 6.0: DCWedge barcode wedge; WES: Freefloat Link*One wedge
Optional Software
Microsoft® Windows® CE 6.0: RFTerm, Wavelink TE, Naurtech CETerm & Industrial Browser, and Stay-Linked Terminal
Emulators Wavelink Avalanche & eXpressConfig network management; WES: Freefloat Access*One terminal emulator
Mass Storage
1GB for Microsoft® Windows® CE; 4GB, 8GB for Microsoft® WES operating system
Graphics Processor
Intel® GMA 500
Power Supply & UPS
10 to 60 VDC isolated, Optional external converters for AC (90-240VAC) & extended range DC (60-150 VDC);
Integrated Li-ION maintenance UPS with 30-min life at -20°C
Display
8˝ (20cm) WVGA (800x480) LED backlit display, Standard 400 NIT indoor display, Optional 900 NIT outdoor
display, Optional screen blanking
Touch Panel
Industrial touch panel with resistive touch and support for finger touch and stylus, Optional touchscreen defroster
Keyboard
Full 64-key QWERTY keyboard w/number pad & 10 function keys, Optional 12-key minimized keyboard with 10
function keys, shift, 2nd & power keys, All keys except modifiers are mappable, All keys backlit, Optional 5250 & 3270
keyboard overlays
Audio
Audio for headset, Integrated stereo speakers w/ adjustable volume control, Integrated microphone
I/O Ports
1x USB 2.0 host port, 1x USB 1.1 client port, 2x RS-232 COM ports, 1x CAN-bus port, 1x Headset port, DC power
input & ignition control input, RF Antenna ports for WiFi (2), WWAN (1) & GPS (1)
Storage Expansion
User installable expansion slot supports 1GB and 4GB SD card
Development Environment
SDK available for Windows® CE 6.0; Standard Windows® SDK for WES 2009
Warranty
1 year factory warranty
Service Plans
Optional one-, three- and five-year service programs offer worry-free mobile computing
Wireless Connectivity
WWAN
Software definable Gobi 2000™ (data only) 3.75G radio with five-band UMTS/HSPA+ (800/850/900/1900/2100MHz),
quadband GSM/GPRS/EDGE (850/900/1800/1900MHz) and dual-band EV-DO/CDMA (800/1900)
WLAN
802.11a/b/g/n, Wi-Fi™ - certified, CCX certified for data
WLAN Security
Authentication: Support for a full range of 802.1X (EAP) types, including EAP-TLS, PEAP-MSCHAPv2, PEAPGTC,
LEAP, and EAP-FAST Encryption: Support for Static, pre-shared, and dynamic encryption keys, 40-bit and
128-bit keys, WEP, WPA (TKIP), and WPA2 (AES) Encryption Methods
WLAN Antennas
Dual internal antennas standard, dual external remote antennas optional
WPAN
Bluetooth® 2.0+EDR standard, internal antenna
GPS
Integrated Assisted GPS (A-GPS) with fast position acquisition and low power consumption
